Shin-Etsu

SIFEL Featured Products

Fluorinated Transparent Adhesive and Gel
X-71-8094-5A/B、X-71-8115A/B

X-71-8094-5A/B and X-71-8115A/B are transparent materials that possess excellent resistance to chemicals and solvents.

Features

  • Usable like silicone-based transparent adhesives and gels
  • Applicable for optical applications in harsh environments
  • Possess excellent resistance to chemicals, solvents, oils, heat and moisture as a result of perfluoropolyether based main chain
  • Keep elasticity in the range of -40ºC~200ºC

Applications

  • Coating for optical fibers
  • Constituent of microfluidic devices
  • LED lenses, Lighting, Diffuser plate
  • Adhesive for Glasses, Sealing.

Page Top

General Properties

Product Name X-71-8094-5A/B X-71-8115A/B
Features Two-component
heat cure adhesive
Two-component
heat cure cohesive
Before Curing
Appearance Pale yellow liquid
Viscosity at 23ºC A:4.8Pa·s A:4.3Pa·s
B:4.3Pa·s B:4.2Pa·s
Density at 25ºC 1.76g/cm3 1.77g/cm3
After Curing (Standard curing conditions:150ºC/1hr)
Hardness Durometer A 28 31

Page Top

Transparency of X-71-8094-5A/B(2mm Thick)

Transparency of X-71-8094-5A/B(2mm Thick)

Selling point

It is a really unique material combining softness, transparency and resistance to chemicals and solvents.
